Description
1
The Room Controller is a wall-mounted control and
display unit for the Tebis system.
It combines several functions in a single unit.
➜
With its 4 touch pads, you can:
- control the lighting, roller blinds, heating, etc.
- have access to advanced functions such as
scenarios
➜
The central screen displays:
- information on the status of the equipment
- the time, date, local temperature, etc.
This information is set using the “Settings” and
“Configuration” modes.
The Room Controller is perfectly suitable for installation
in the main rooms of a house, apartment or small office.
58
Contents
1. Description . . . . . . . . . . . . . . . . . . . .59
2. Installation . . . . . . . . . . . . . . . . . . . . .60
2.1 Connection . . . . . . . . . . . . . . . . . . . . . . . .60
2.2 EIB configuration . . . . . . . . . . . . . . . . . . . .61
3. Description . . . . . . . . . . . . . . . . . . . .62
3.1 The touch pads . . . . . . . . . . . . . . . . . . . . .62
3.2 The screen . . . . . . . . . . . . . . . . . . . . . . . .63
3.3 The local temperature sensor . . . . . . . . . .64
3.4 The alarm clock . . . . . . . . . . . . . . . . . . . . .64
4. The various modes . . . . . . . . . . . . . .65
5. Settings mode . . . . . . . . . . . . . . . . . .66
5.1 Time - date . . . . . . . . . . . . . . . . . . . . . . . .67
5.2 Alarm clock . . . . . . . . . . . . . . . . . . . . . . . .68
5.3 Alarm bell . . . . . . . . . . . . . . . . . . . . . . . . .69
5.4 Contrast . . . . . . . . . . . . . . . . . . . . . . . . . .69
5.5 Backlighting . . . . . . . . . . . . . . . . . . . . . . .69
5.6 Touch pad beep . . . . . . . . . . . . . . . . . . . . .70
5.7 Date format . . . . . . . . . . . . . . . . . . . . . . . .70
5.8 References . . . . . . . . . . . . . . . . . . . . . . . .70
6. Configuration mode . . . . . . . . . . . . . .71
6.1 Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
6.2 Display . . . . . . . . . . . . . . . . . . . . . . . . . . .76
6.3 Choice of language . . . . . . . . . . . . . . . . . .80
6.4 To reset to zero . . . . . . . . . . . . . . . . . . . . .80
7. Faults and maintenance . . . . . . . . . .81
7.1 Error messages . . . . . . . . . . . . . . . . . . . . .81
8. Technical characteristics . . . . . . . . . .83
