83
hager
GB
Technical characteristics
8
EIB bus power supply 29 V DC TBTS
Current consumption ≈ 7,5 mA (without backlighting)
at 29V ≈ 15 mA (with backlighting)
Max. power dissipation
≈ 430 mW (with backlighting)
Overall dimensions
≈ 80,5 x 80,5 x 15,4 mm (excluding BCU)
Connection bus connection terminal
0,6 to 0,9 mm
2
rigid wire
Mounting in diameter 60 mm
connection box depth 40 mm minimum
Protection grade IP20
Built-in temperature Accuracy of temperature
sensor measurement: +/- 0.5 °C
Range of measurement
0°C to +45°C
Operating 0°C to +45°C
temperature
Storage -20°C to +70°C
Temperature
CEM EN 50090-2-2
EN 55022
EN 55024
EN 60669-2-1
82
7
Dépannage et maintenance
Clean the Room Controller with a clean, soft, damp cloth.
Do not use alcohol, aerosols or solvent or abrasive pro-
ducts that could damage the finish of the Room
Controller.
General care
