GB
12
• Battery Level Indication
Check the battery level indication on the LCD panel to see the
remaining battery level.
Attaching to Camera
Power Management
Long press the Power button to power the flash unit on or off.
• Used on camera or as a master flash, it will turn the power off
automatically after a certain period (approx. 90 seconds) of idle use.
Battery Level indication
2 bars
1 bar
no bar
no bar “Flashing”
Status
Full
Some remaining power
Low
The battery level is going to run out
immediately. Please recharge the
battery as soon as possible.
b
c
a
1. Attach the Speedlight to the
camera. Slip the flash’s mounting
foot into the camera’s hotshoe
all the way.
2. Secure the Speedlight. Rotate
the lock ring to the right until it
clicks into position.
3. Detach the Speedlight:
a) Push the release button.
b) Rotate the lock ring to
the left until it is loosened.
c) Slide the speedlight off the
camera hotshoe
