Halton KVE-WW - KSA Filter Management; KSA Filter Removal and Installation with KFR Tool

17
Capture Jet
®
Water Wash
Operation & Maintenance & Service Manual
CJOWWM/012009/rev1/EN
To assemble the KFR lter remover:
Screw together stainless steel pipe, coupling, and bracket and tighten all joints. (as shown in above picture)
KSA Filter Removal
with Model KFR
To remove lter:
Insert bracket into the inside KSA lter slots, and lift
upward until lter slides out of plenum.
To install lter:
Place lter on KFR (lter removal tool) bracket, raise lter
into place inside exhaust plenum. Slide upward until
top lip of lter is locked into place and bottom lip of lter
slides in place inside the exhaust plenum.
*** It is very Important to lock top lip of lter in place
in installation as shown in reference drawing.
To remove
lter
To install
lter
Filter Installation and Removal
16 ga. S.S. Bracket
S.S. Coupling
S.S. Pipe
