Halton KVE-WW - Model-Specific Installation Examples; KVE-WW Model Typical Installation Diagram

18
Capture Jet
®
Water Wash
Operation & Maintenance & Service Manual
CJOWWM/012009/rev1/EN
Model KVE-WW
Typical Installation
**Incandescent or
Fluorescent lighting
available.
KSA Filters
78”-84” A.F.F.
Standard
**(Verify with Authority
in project location for
min. hanging height)
16 ga. duct work all
welded per code
Standard Capture Jet
®
intake location
**(optional top mounted
Capture Jet intake also
available)
Capture Jet
®
Airow
40 “ min.
UL listed upblast fan for restaurant
cooking appliances
