Halton KVE-WW - KVC-WW Model Typical Installation Diagram

19
Capture Jet
®
Water Wash
Operation & Maintenance & Service Manual
CJOWWM/012009/rev1/EN
Model KVC-WW
Typical Installation
Filtered MUA
unit on the
roof
40” min.
120” min.
16 ga. duct work all
welded per code
Stainless
Steel KSA
lters
Capture Jet
®
air
78” - 84” A.F.F.
78” Std.
Make-up airow
**(Verify with Authority
in project location for
min. hanging height)
