4
80-150 kW Frame & Header Kits Manual
Product Number Frame and Header Size PHEX kW
232893 DN80 150
232894 DN80 300
232895 DN80 450
232896 DN80 300
236388 DN100 300
236389 DN100 450
232902 DN100 600
232897 DN100 750
232904 DN100 900
System separation PHEX kits are o󰀨ered at the below kW ratings and are supplied with suitable pipe spools for connection to
frame and header kits.
Table 5 System Seperation PHEX Kits
