80-150 kW Frame & Header Kits Manual
5 LOW LOSS HEADER ASSEMBLY (OPTIONAL ACCESSORY)
4.2 BOILER MOUNTING
1. As appropriate mount the boilers onto either the wall plates or the side by side pipekit.
5.1 FITTING LOW LOSS HEADER AND BLANKING FLANGES
1. Fit the low loss header and blanking anges in the chosen positions.
Note. Low loss header can be located either LHS or RHS of the headers.
Low Loss Header
Blanking Flange
Note. For instructions relating
to PHEX accessory,
please see separate
installation manual.
