HANGCHA CDD12-AC1 - Page 29

25
Mast Specification：1.2t/1.4t/1.6t
Mast type
Max Lifting
Height
h3
Ground
Clearance,fork
(h3+h13)
Lowered
Height
h1
Extended
Height
h4
Free lift
mm mm mm mm mm
Double
cylinders
duplex wide
view
2000 2090 1542 2542 90
2500 2590 1792 3042 90
2700 2790 1892 3242 90
3000 3090 2042 3542 90
3300 3390 2192 3842 90
3500 3590 2292 4042 90
3600 3690 2342 4142 90
3800 3890 2442 4342 90
4000 4090 2642 4642 90
4300 4390 2792 4942 90
Duplex full-free
wide view
2000 2090 1595 2595 1090
2500 2590 1845 3095 1340
2700 2790 1945 3295 1440
3000 3090 2095 3595 1590
3300 3390 2245 3895 1740
3500 3590 2345 4095 1840
3600 3690 2395 4195 1890
Triplex full-free
wide view
3500 3590 1844 4214 1220
3700 3790 1909 4409 1290
4000 4090 2009 4709 1390
4300 4390 2109 5009 1490
4500 4590 2159 5159 1590
4700 4790 2259 5459 1590
5000 5090 2354 5744 1700
5200 5290 2409 5909 1790
