Mast Specification：2.0t
Mast type
Max Lifting
Height
h3
Ground
Clearance,fork
(h3+h13)
Lowered
Height
h1
Extended
Height
h4
Free lift
mm mm mm mm mm
Double
cylinders
duplex wide
view
2000 2090 1647 3647 90
2500 2590 1897 3147 90
2700 2790 1997 3347 90
3000 3090 2147 3647 90
3300 3390 2297 3947 90
3500 3590 2397 4147 90
3600 3690 2447 4247 90
Duplex full-free
wide view
2000 2090 1700 2700 1090
2500 2590 1950 3200 1340
2700 2790 2050 3400 1440
3000 3090 2200 3700 1590
3300 3390 2350 4000 1740
3500 3590 2450 4200 1840
3600 3690 2500 4300 1890
Triplex full-free
wide view
3500 3590 1944 4314 1130
3700 3790 2009 4509 1200
4000 4090 2109 4809 1300
4300 4390 2209 5109 1400
4500 4590 2259 5259 1500
4700 4790 2359 5559 1500
