17
3.2 PROBE SPECIFICATIONS
Non-logging Probe Logging Probe
Sample Environment Fresh, brackish, seawater
Waterproof protection IP68
Computer Interface NA USB PC (HI 76982910)
Internal Battery Type NA 4 X 1.5V Size AA Alkaline
Typical Battery Life NA See below
Memory NA 140,000 measurements
(single parameter logged)
35,000 measurements
(all parameters logged)
Operating Temperature -5 to 55° C *
Storage Temperature -20 to 70° C
Maximum Depth 20 m (66 ft.) *
Dimensions HI 7609829 342mm (13.5”), HI 7629829 442mm (17.4"),
(without cable) dia=46 mm (1.8”) dia=46 mm (1.8")
HI 7619829 382 mm (15.1”), HI 7639829 482 mm (19.0"),
dia=46 mm (1.8”) dia=46 mm (1.8")
Weight HI 7609829 570g (20.1 oz.) HI 7629829 775g (27.3 oz.)
(with batteries and sensors) HI 7619829 650g (22.9 oz.) HI 7639829 819g (28.9oz.)
Cable Specification Multistrand-multiconductor shielded cable with internal strength
member rated for 68 kg (150 lb) intermittent use
Wetted Materials Body: ABS
Threads: Nylon
Shield: ABS/ 316 SS
Temp probe: 316 SS
O-rings: EPDM
* Reduced for ISE sensors
LOGGING PROBE BATTERY LIFE
Interval All channels logging All channels logging
(no averaging) (10 sample averaging)
1 - 5 sec 72 hours 72 hours
1 min 22 days 11 days
10 min 70 days 65 days
