5 User Interface – Icons
Log recall Description
Table view, function active / not selected
Graph view, function active / not selected
Information view, function active / not selected
General Description
Profile
Background operation in progress
Alarm enabled
Stability / Autohold indicator
Connectivity & Printing Description
Ethernet
Connection established (tap for IP address)
0.5 sec
Connection in progress
Connection error
Wi‑Fi
Connection established (tap for IP address)
0.5 sec
Connection in progress
Connection error
USB
USB‑A or USB‑C flash drive plugged in
High‑power consumption with the flash drive plugged in
PC
PC connection established through USB‑C port
Printer
Printer connected ‑ printing manual log option enabled
Printer connected ‑ printing manual log option disabled
Printer not recognized or no longer connected
