Cable holder clip
The holder is delivered with a cable holder clip (attached) that secures several cables whilst allowing them to
move freely with the arm motion.
1. To open the latch, press the clip inward while pulling up the latch.
2. To close the latch, lower latch over cable and snap closed.
The latch snaps in position and secures the cables inside.
press
pull
To reattach the clip onto the electrode arm:
1. Align the clip’s dovetail over the slot.
2. Gently push down to slide in position.
7.2. USING THE ADAPTER
The electrode arm is ended with an electrode holder. The holder is fitted with an adapter that has two
different‑sized apertures:
• center‑back (optical and polarographic probe, with adapter only)
• left and right (polarographic probe only)
Insert clip
To Next Page
