Hanna Instruments HI6421 - Probes

Functional & LCD Description 14
6.2. PROBES
HI7641133 Optical Probe
1
2
3
4
5
7
6
8
1. Cable
2. Cable relief
3. Probe body
4. Temperature sensor
5. Optical window
6. Embedded O
2
sensitive luminophore with
oxygen‑permeable black protective layer
7. Smart Cap
8. DIN Connector
3
5
6
4
2
1
DETAIL A
A
1. Alignment key
2. O‑ring seal
3. Optical window
4. Smart Cap
5. Data storage tag
6.
Embedded O
2
sensitive luminophore with
oxygen‑permeable black protective layer
