Chapter 11 - PC CONNECTION MODE
The logged data from a probe or meter can be transferred to a PC using the HI9298194
Windows
®
compatible application software. HI9298194 offers a variety of features and on‑line‑help is
available.
HI9298194 allows data to be imported into most spreadsheet programs (e.g. Excel
©
,
Lotus 1‑2‑3
©
). After the data has been imported into a spreadsheet, all features of the spreadsheet
program can be used to analyze and graph the data.
SOFTWARE INSTALLATION
• Insert the installation CD into the PC.
• The software menu window should start automatically (if it does not, navigate to the main CD
folder and double‑click “setup.exe”).
Click “Install software” and follow the instructions.
METER TO PC CONNECTION
• With the meter OFF, disconnect the probe.
• Connect the USB cable to the meter and to a USB port on the PC.
• Turn the meter ON and the message “PC connected” will be displayed.
• Run the HI9298194 application software.
• Press Setting button on the top of the screen and select the
measurement units you which your data to appear with.
• To access the meter data select the “Meter” button on the
toolbar at the top of the screen.
The PC‑Meter connection will be established and a new window
will be displayed with meter data: status information (software version and date, SN, ID, battery
level and free memory info), as well as a summary of logged data lots.
The lots logged on the meter can be saved to the PC by pressing the “Download lot” button after
the desired lot is selected.
• Once the lot has been downloaded, all the logged samples can be viewed.
Windows
®
is a registered Trademark of “Microsoft Co.”
PC CONNECTION MODE
