Hansa C40 O&M Manual – OM-013 Revision E 23/10/19
© Hansa Chippers 2019
22
Hydraulic oil tank
Hydraulic oil tank
Oil pressure bypass
button
Next to the oil pressure bypass button
Feed roller motor
safety
Feed roller motor
Feed roller motor
safety (keep clear)
Top face of feed roller cover
Bonnet (Do not open)
Top face of engine bonnet
