Hansa C40 - Bolt Torque Specifications; Technical Specifications

Hansa C40 O&M Manual – OM-013 Revision E 23/10/19
© Hansa Chippers 2019
19
Bolt torque
When servicing the machine, ensure any bolts you remove are torque to the values listed in the torque table below:
Relative Strength Bolt Marking
4.6
8.8
Recommended Tightening Torque
Recommended Tightening Torque
Bolt size
Spanner size
lb ft
Nm
lb ft
Nm
M8
13 mm
6
8.5
16
22
M10
16 mm
12.5
17
32
44
M12
18 mm
22
30
57
77
M16
24 mm
54
73
140
190
M20
30 mm
105
143
274
372
Specifications
C40
General
Length
3555 mm
Width
1575 mm
Height
2060 mm
Weight
1160 kg
Engine
Make & model
42 HP Kohler air cooled
Type of fuel
Diesel
Capacities
Fuel tank
45 L
Hydraulic oil tank
24 L
Chassis
Frame description
100 x 50 x 5 mm RHS
Wheels
13” wheels
Cutting System
Disc speed
1800 RPM
Disc diameter
650 x 25 mm
Shaft diameter
50 mm
Knives
Two
Feed System
Feed opening
330 x 178 mm (13” x 7”)
Chipping capacity
178 mm (7”)
Feed table height
750 mm
Feed table length
1550 mm
Inlet chute opening
960 x 650 mm
Roller Style
Single roller, spring mounted, 220 mm (8.7”) diameter
Feed speed range
0-40 m/min (135 f/min), full reverse
Discharge System
Discharge height
2060-2200 mm (adjustable)
Degree of rotation
360°
Transmission System
Belt drive
3x SPB1260
