Product Overview
EN
DPO7000 Quick Guide Copyright © Qingdao Hantek Electronics Co., LTD
10
4 Product Overview
10.1 inch multi-touch capacitive screen, 256 level waveform grayscale and color
temperature display, 500MHz bandwidth, 2GSA/s sampling rate, 2G storage depth,
500.000wfms/s waveform capture rate; Equipped with a 25MHz signal generator,
supporting any wave output; 41 types of automatic measurement, providing full memory
hardware measurement function; Rich serial protocol triggering and decoding functions;
Multiple data analysis and processing functions; Integrating 7 instrument functions,
significantly simplifying the measurement system and accelerating measurement speed;
Provide rich configuration interfaces for more convenient use; It is a trustworthy
oscilloscope that can provide you with professional level measurements.
4.1 Front Panel Overview
