Safety requirement
EN
Copyright © Qingdao Hantek Electronics Co., LTD DPO7000 Quick Guide
3
This instrument can be used for measurement under class I.
Warning:
This instrument is only allowed to be used in the specified measurement class.
Measurement class definition
⚫ Class I refers to measurements taken on a circuit not directly connected to
the main power supply. For example, measurements made on circuits that are not
exported from a main power supply, especially from a protected (internal) main
power supply. In the latter case, the instantaneous stress will change. Therefore,
the user should understand the instantaneous capacity of the instrument.
⚫ Class II refers to measurements taken on a circuit directly connected to
low-voltage instruments. For example, measurements made on household
appliances, portable tools, and similar equipment.
⚫ Class III refers to measurements taken on construction equipment. For
example, measurements made on switchboards, circuit breakers, circuits (including
cables, busbars, junction boxes, switches, sockets) in fixed equipment, as well as
equipment for industrial use and certain other equipment (for example, fixed motors
permanently connected to fixed instruments).
⚫ Class IV refers to measurements taken at the source of low-voltage
equipment. For example, measurements made on electricity meters, primary
overcurrent protection equipment, and pulse control units.
1.4 Ventilation Requirement
This oscilloscope uses a fan to force cooling. Please make sure that the air intake and
exhaust areas are free from obstructions and have free air. When using the oscilloscope
in a bench-top or rack setting, provide at least 10 cm clearance beside, above and
behind the instrument for adequate ventilation.
Note:
Inadequate ventilation may cause an increase of temperature in the instrument,
which would cause damage to the instrument. So please keep the instrument well
ventilated and inspect the air outlet and the fan regularly.
1.5 Working Environment
Temperature
Operating: 0°C to 50°C
Non-operating: -30°C to 70°C
Humidity
