Hantek DPO7000 Series User Manual

Document overview
EN
Copyright © Qingdao Hantek Electronics Co., LTD DPO7000 Quick Guide
7
2 Document overview
This document describes how to quickly understand the front and back panels, user
interfaces, and basic operation methods of the DPO7000 series digital oscilloscopes.
Tip:
The latest version of this manual can be downloaded at (http://www.hantek.com).
Document number:
202304
Software version:
Software upgrade may change or increase product functionalities, please pay attention
to Hantek website for the latest version.
Document format conventions:
1 Virtual keys and main interface icons
Use [name] to represent virtual keys and main interface icons. For example, [Utility] is
for .
2 Menu
Use "menu text (bold) + color" to represent a label or a menu option. For example, I/O
means to click the "I/O" option on the current operation interface to enter the function
configuration menu of "I/O".
3 Operation steps
Use "->" to represent the next step. For example, [Utility] -> Language means click
Utility label before clicking Language menu.
Document content conventions:
DPO7000 series tablet oscilloscope consists of the following models. Unless otherwise
specified, this manual uses DPO7504E as an example to describe the DPO7000 series
and basic operations.
Model
Bandwidth
Channel
Signal source
Digital Channels
DPO7104E
100MHz
4
1
16
DPO7102E
100 MHz
2
1
16
DPO7104C
100 MHz
4
-
-

Hantek DPO7000 Series Specifications

General

Brand	Hantek
Model	DPO7000 Series
Category	Test Equipment
Language	English
