13
control of waveforms is available during Roll Mode, and it‟s only available when set to
100ms/div or slower. Press Time->Mode to change the display mode to Roll, the time/div
will be changed to 100ms/div automatically.
Scan: In Scan Mode, the waveform display scan updates from left to right. In Scan mode,
trigger and horizontal offset control of waveforms are available during Scan Mode. This
mode is only available when set to 100ms/div or slower. Generally, used for measuring
low frequency signal. When the time/div is 100ms/div or slower, the oscilloscope
automatically enters the scan mode.
Vertical System
Vertical system can be used to adjust the vertical scale and location and other settings of
the channel. Each channel has a separate vertical menu, and each channel can be set
separately.
1. Vertical Position
Press Channel->F1 to select the channel, and press Up or Down direction keys to
move the vertical position of the selected channel.
2. VOLTS/DIV Settings
The range of Volt/div is 10mV/div-10V/div (1X), or 100mV/div-100V/div (10X),
1V/div-1000V/div (100X), step by 1-2-5.
Press Channel->F1 to select the channel, and press Right or Left direction keys to
change the Volt/div of the selected channel.
3. Channel Setting Menu
Options
Settings
Comments
On/Off
On
Off
Turn on the waveform display.
Turn off the waveform display.
Coupling
DC
AC
GND
DC passes both DC and AC components of the input
signal.
AC blocks the DC component of the input signal and
attenuates signals below 10Hz.
GND disconnects the input signal.
Probe
1×
10×
100×
1000×
10000×
20:1
Selects a value according to the probe attenuation
factor so as to ensure correct vertical readouts.
Reduce bandwidth to 6MHz when using a 1X probe.
CC-65 1
1mV/10mA
CC-65 2
1mV/100mA
CC-650 1
1mV/100mA
CC-650 2
1mV/1A
