4. Press F4 to save the current waveform to the specified location..
Measurement
Scale measurement
Graticule: This method allows you to make a quick, visual estimate and take a simple
measurement through the graticule divisions and the scale factor.
For example, you can take simple measurements by counting the major and minor
graticule divisions involved and multiplying by the scale factor. If you counted 6 major
vertical graticule divisions between the minimum and maximum values of a waveform and
knew you had a scale factor of 50mV/division, you could easily calculate your
peak-to-peak voltage as follows:
6 divisions x 50mV/division = 300mV.
Cursor measurement
The cursor measurement has two parallel lines on the screen, and move two lines to
measure the time and voltage parameters of the input signal. The result of cursor
measurement will be displayed on the second page of the cursor menu. Before use cursor
measurement, make sure that the measured source is the signal you need to measure.
Press button to enter, and select Cursor to enter cursor measurement.
Cursor Measurement Menu Table
Open the cursor measurement.
Close the cursor measurement.
The horizontal line is shown to measure the voltage
parameters.
The vertical line is shown to measure the time
parameters.
Select the measured source.
Select Cursor1 and press up, down, left and right keys to
move the Cursor1 position, and display the Cursor1 value.
Select Cursor2 and press up, down, left and right keys to
move the Cursor2 position, and display the Cursor2 value.
The difference between the Cursor1 and the Cursor2.
To do cursor measurement, follow these steps:
1. Press F1 to open the cursor measurement;
2. Press F2 to select a type of cursor measurement.
3. Press F3 to select the channel that needs to be measured.
4. Press F4 to enter the second page, press F1 or F2 to select Cursor1 or Cursor2, press
up, down, left and right to move Cursor1 or Cursor1;
