HT2018B(C) Battery System Tester 8
The test result shows that the battery life is only 32%, and the performance is poor.
Recommended to replace.
3) Life is normal and voltage is low
The test result shows that the battery life is 100% and the performance is excellent,
but the battery voltage is only 12.11V. Recommended to charge.
4) Life is normal and voltage is too low
The test result shows that the battery voltage is only 11.88V, battery voltage is too
low. That may affect the test results. It is recommended to test again after charging.
5.3 Startup Load Test
5.3.1 Preparation before testing
If the car is in motion, please turn off the fire and turn the key to OFF position.
5.3.2 Operation
1) Connect the red test clamp to the battery positive pole, connect the black test clamp to
the battery negative pole. Attention must be made to good contact so as not to affect test
results.
2) Press < > < > button to select Start Load Test, and press <ENTER> to enter the
selection, as follows:
