HT2018B(C) Battery System Tester 11
5.5 Charging System Test
5.5.1 Preparation before testing
If the car is flameout, please start the car.
5.5.2 Operation
1) When the car is in the starting state, connect the red test clamp to the battery positive
pole, and connect the black test clamp to the battery negative pole. Attention must be
made to good contact so as not to affect test results.
2) Press < > < > button to select Charging System Test, as follows:
3) Press <ENTER> to enter, The instrument will show the following picture:
4) According to the prompt in the Step 3 to operate, and press <ENTER> to enter. The
test result will be displayed as follows:
The current voltage is 13.88V, the standard maximum voltage is 15.00V (for 6V
system, the standard maximum voltage is 7.50V; for 24V system, the standard
maximum voltage is 30.00V), and the maximum voltage is 14.10V.
The current voltage is 13.88V, the standard minimum voltage is 13.30V (for 6V
system, the standard minimum voltage is 6.6V; for 24V system, the standard
minimum voltage is 26.60V), and the minimum voltage is 13.58V.
5) Press the < ESC > button will return to step (2).
5.5.3 Charging system problematic
