HT2018B(C) Battery System Tester 9
3) The test result will be displayed as follows:
The diagram respectively shows the current test voltage (static voltage) is 12.36V, the
standard voltage is 9.6V (for 6V system, the standard voltage is 4.8V; for 24V system,
the standard voltage is 16V), and the lowest start-up voltage is 12.30V during startup.
4) Start the car, the tester will automatically test and record the minimum voltage that the
battery output during starting the car.
5) Press the < ESC > button will return to step (2).
5.3.3 Start load test results instruction
◆ If the lowest voltage is greater than 9.6V (for 6V systems, voltage is greater than
4.8V; for 24V systems, voltage is greater than 16V), the startup system is good.
◆ If the minimum voltage is less than 9.6V (for 6V systems, voltage is less than 4.8V;
for 24V systems, voltage is less than 16V), the startup system is problematic. Please
check the relevant parts such as connection points, wires, starters, and whether
there is rust at the battery terminals.
