To attach light kit fitter (D) to motor assembly (C),
align holes in switch housing cap, at top of light
kit fitter (D), with holes in switch housing. (Make
sure to align gap on top edge of the switch
housing cap with the reverse switch on switch
housing for the correct fit.) Re-insert switch
housing cap screws (U) that were removed in
Step 4 on the previous page and use a Phillips
screwdriver (not included) to secure all switch
housing cap screws (U).
6.
7.
Install three candelabra-base 40-watt max.
bulbs (M) included.
IMPORTANT: When you need to replace bulbs,
please allow bulbs and light kit to cool down
before touching the bulbs or the light kit.
12
Lowes.com/harborbreeze
7
6
M
FINAL INSTALLATION
C
Switch
Housing
Cap
Switch
Housing
U
D
To Next Page
