3 - Description
24
Boom
Boom Operator’s Manual
A separate “Boom Operator’s Manual” is supplied with your sprayer and contains detailed information on boom safety,
set-up, operation and maintenance.
€
DANGER! Important information on Safety, Operation and Maintenance specific to your boom configuration is
detailed in the “Boom Operator’s Manual” supplied with your sprayer. It must be read and fully understood by anyone
intending to operate this equipment. Failure to do so could result in serious personal injury or death.
AutoTerrain (optional)
AutoTerrain is a computer controlled pre-emptive boom stability and
auto height control system which maintains the correct relationship and
height of the boom to the different field conditions. AutoTerrain highly
tuned computer controlled proportional electro-hydraulics and
ultrasonic sensors help spray more safely, reducing potential ground
strikes and prevents incorrect spray height.
±
WARNING!
• Stability control roll sensor and indicator must be correctly aligned
to prevent uncontrolled and continuous boom oscillation.
• The pendulum center stability control linkage points must be
regularly lubricated to protect swivel balls from moisture
penetration and prevent swivel ball seizure.
• The boom should never be used to spray with the pendulum lock
engaged.
ATTENTION!
• For optimum AutoTerrain performance the stability & height
control sensors must be checked and cleaned regularly.
• Dusty, damp or missing sensors pads will not read accurately and
AutoTerrain will be compromised. Foam pads must be washed and
dried daily. The boom should not be used if foam pads are missing
from the sensors.
• Regarding AutoTerrain, please refer to specific book for information
about Operation, Calibration and Maintenance.
