3 - Description
25
Hydraulic systems
Hydraulic blocks
Hydraulic blocks fitted to the sprayer are:
Boom
The main boom hydraulic block that manages hydraulic pressure for the
boom controls.
The throttle valve (A) can adjust the folding speed of the boom.
Adjusting inwards = slower boom.
ParaLift
This hydraulic block manages hydraulic pressure for the ParaLift.
