23
P R A C T I C A L
Measured xxx m
C A L I B R A T I O N
Revolutions cal.
R E V O L U T I O N S C A L .
x . x P P R
A L A R M S
Tank alarm
Method
1. Measure a distance not less than 75 metres.
2. Park the tractor at the start of the measured distance.
3. Open menu. When zero distance [ 0 m ] shows, drive the meas-
ured distance.
4. Correct the distance shown on the display with the arrow key to
read the actual distance
Revolutions calibration
For calibration of revolutions transducer.
The constant, pulse per revolution (PPR), is
the number of pulses for one revolution.
For example, if one magnet is tted, the PPR is 1.0.
Alarms
There are 2 alarms, a tank alarm for low tank contents and a volume rate alarm
for over or under application. When outside the alarm parameters, the relevant
warning will ash. A beeper can also be activated.
Low tank contents alarm.
