3 - Description
45
Rear view
14. Pump for liquid system.
15. Hose reel and spray gun for cleaning.
16. Adjuster screw for BoomPrime system.
17. Pressure gauge for BoomPrime system.
18. Operating unit. Electric valve control (EVC).
19. Safety locker. Two-room storage for safety gear.
20. Traffic lights. For connection to tractor’s 7-pin socket.
21. Footboard. Easy access for filling, cleaning of tank, etc.
22. Pressure gauge for spray boom (combined with item 4).
23. InLine filters. Minimize stoppage of spraying due to nozzle blockages.
24. Lid for main tank. The filling hole is placed, so that it can be accessed from the footboard.
25. RinseTank(s) 80 litres.
20
18
22
24
16
17
15
23
21
19
14
25
25
