6.10 Manifold System (cont'd)
• Return to Tank
• Return to
Pump
Blue Disk= Agitation Bypass Valve
• From Flush
Tank
• From Main tank
Black Disk= Suction Valve
• To Chemical Filler
• To Hose reel
/spray gun
Green Disk= Pressure Valve
• TO ESC Control • To Tank Rinse
nozzle
