HARDI MEGA 230 / 350 CENTRIFUGAL OPERATORS MANUAL
11.5 Hydraulics
Restrictor
Fig. 48
HZ-Model Won't Fold
PROBLEM SOLUTION
Hydraulic lines not hooked- Check the lines for proper
up properly hook-up
Switches for hydraulic functions Tun the proper switches on
not turned on
Cable from sprayer not attached Attach cable to control box
to control box
No power supply to control Check all connections and
box cables in power supply
Cable from control box to Replace cable
hydraulic manifold is damaged
HY/HZ-Model Won't Fold
PROBLEM SOLUTION
Hydraulic lines not hooked- Check the lines for proper
up properly hook-up
Dirt in the restrictors on the Remove restrictors and
cylinders clean them
