HARDI MEGA 230 / 350 CENTRIFUGAL OPERATORS MANUAL
6.14 Nozzle Selection (cont'd)
371551
LARGE DROPLET FLAT SPRAY
TIP IN 150 DEGREE SPRAY
ANGLE. Always used in
conjunction with 1553-14-16-18 or
20 cone nozzle. 50,80 or 100
mesh screens are normally used
with these nozzles.
1553 less swirl
SOLID STREAM NOZZLE for high
volume liquid fertilizer application.
In this application, the 1553
nozzle is always used with
330013 o-ring and 50,80 or 100
mesh screens.
371537
thru
371543
3-HOLE NOZZLE-SYNTAL/
CERAMIC this nozzle disperses
the spray liquid in three solid
streams, thereby reducing the
number of plants at risk of
scorching by the application of
liquid fertilizer.
