New NAV I GA TOR

Operator’s Manual

HARDI

reserves the right to make changes in design,

material, or speciﬁ cation without notice thereof.

HARDI

and other product names are registered trademarks

of HARDI

Inc. in the U.S. and in other countries.

67020803 (10/04)

Default Chapter4
- Table of Contents4
Introduction6
Description7
- Frame7
- Adjustable Wheel Spacing7
- Suspension (Optional)7
- Tank7
- Pump7
- HARDI ® SMART VALVE MANIFOLD System7
- ECP Operating Unit7
- ECPC Operating Unit7
- Filters (Standard and Optional)7
Safety Instructions8
- Operating the Sprayer Safely8
- Handling Chemical Products Safely9
- Local Poison Information Center9
Connection10
- Support Jack10
- Bottom Step (Optional)10
Shaft11
- P.T.O. Shaft Operator Safety11
- Installation of P.T.O. Shaft11
Wheel Spacing Adjustment (Suspended and Non-Suspended Axle)12
Axle Clearance Adjustment (Suspended and Non-Suspended Axle)12
Tires13
Hydraulic System13
- Connection Requirements13
- Hydraulics - Standard Joystick Handle14
- Direct Acting Hydraulic System (D.H.)14
- Connecting Electric Controls15
- Disconnecting Sprayer15
- Before Operating Sprayer15
Transport15
- Roadworthiness15
- Rear Lights15
- Transport Bracket Settings16
- Adjusting Boom Transport Position16
ECP Plumbing Diagram17
ECPC Plumbing Diagram18
Operation19
- Operation of Spraying Functions19
- Filling Tanks with Water19
- Tank Capacities19
- Filling through Tank Lids19
Quick Fill (Optional)20
- General Quick Filling Guidelines20
ECP & ECPC Operating Unit21
- Controls Adjustment21
- Adjustment of Constant Pressure21
- Operating the Control Unit While Spraying21
- Emergency Operation22
- Remote 4" Pressure Gauge (Optional)22
- Filters22
- Self Cleaning Fi Lter (ECP Only)22
Adding Chemicals23
- Filling through the Tank Lid23
- Filling with the HARDI ® Chemical Fi Ller (Optional)23
- Operating with Liquid-Based Chemicals23
- Operating with Powder-Based Chemicals24
Use of Fl Ush Tank and Rinse Nozzles (Optional)25
- Technical Residue25
- Draining Tanks25
Nozzle Selection26
Calibration28
Maintenance - Rules of Thumb29
- Cleaning the Sprayer29
- Guidelines29
- Cleaning the Tank30
- Cleaning and Maintenance of Fi Lters30
Lubrication31
- About Lubricants31
- Recommended Lubricants31
- Lubrication Schedule32
Service and Maintenance Intervals35
- Hours Service35
- Hours Service36
- 1000 Hours Service37
- Occasional Maintenance37
Off-Season Storage41
- Preparation after off Season Storage41
Equipment and Accessories42
Troubleshooting45
Emergency Operation of the Sprayer50
Technical Speciﬁ Cations51
- Overall Measurements51
- Weight51
- Filters and Nozzles52
- Temperature and Pressure Ranges52
- Electrical Connections Rear Lights52
- Electrical Connections for ECP/ECPC Operating Unit52
- EAGLE™ Boom Hydraulics SPB-HZ and SPC-HZ53
- EAGLE™ Boom Hydraulics SPB-HY and SPC-HY53
- DH Hydraulics54
Warranty Policy and Conditions55
Notes57
