Harman Kardon AVR 1700 User Manual

AVR
35
English
Appendix
Table A9 – Remote Control Function List
No.
Button
Name
AVR
Function
DVD
Blu-ray Disc
Player
Game TV TiVo/DVR
DMC Music
Server
Cable
Tuner
Satellite
Tuner
iPod/USB
01 Power On Power On Power On Power On Power On Power On/Off Power On Power On Power On Power On
02 Power Off Power Off Power Off Power Off Power Off TV Power Power Off Power Off Power Off Power Off
03 Mute Mute Mute Mute Mute Mute Mute Mute Mute Mute Mute
04 AVR AVR Select AVR Select AVR Select AVR Select AVR Select AVR Select AVR Select AVR Select AVR Select AVR Select
05 Cable/Sat Cable/Sat Select Cable/Sat Select Cable/Sat Select Cable/Sat Select Cable/Sat Select Cable/Sat Select Cable/Sat Select Cable Select Sat Select Cable/Sat Select
06 TV TV Select TV Select TV Select TV Select TV Select TV Select TV Select TV Select TV Select TV Select
07 Disc Disc Select Disc Select Disc Select TV Select Disc Select Disc Select Disc Select Disc Select Disc Select Disc Select
08 Server Server Select Server Select Server Select Server Select Server Select Server Select Server Select Server Select Server Select Server Select
09 Aux Aux Select Aux Select Aux Select Aux Select Aux Select Aux Select Aux Select Aux Select Aux Select Aux Select
10 Game Game Select Game Select Game Select Game Select Game Select Game Select Game Select Game Select Game Select Game Select
11 STB STB Select STB Select STB Select STB Select STB Select STB Select STB Select STB Select STB Select STB Select
12 Audio Audio Select Audio Select Audio Select Audio Select Audio Select Audio Select Audio Select Audio Select Audio Select Audio Select
13 Radio Radio Select Radio Select Radio Select Radio Select Radio Select Radio Select Radio Select Radio Select Radio Select Radio Select
14 USB USB Select USB Select USB Select USB Select USB Select USB Select USB Select USB Select USB Select USB Select
15 Network Network Select Network Select Network Select Network Select Network Select Network Select Network Select Network Select Network Select Network Select
16 CH+ Audio Channel + Channel + Audio Channel + Channel + Channel +
17 Test Tone Test Tone Find Find
18 CH. Channel Audio or Playlist Audio Status
19 Vol Up Volume Up Volume Up Volume Up Volume Up Volume Up Volume Up Volume Up Volume Up Volume Up Volume Up
20 CH- Disc Menu or Title
Disc Menu or Top
Menu
Scan Down Channel - Channel - Title Channel - Channel - Channel -
21 Tone Tone Controls
PIP Audio or
PopUp Menu
V-Off Tone Controls
22 Delay Delay Adjust Repeat Repeat Delay Adjust
23 Vol Down Volume Down Volume Down Volume Down Volume Down Volume Down Volume Down Volume Down Volume Down Volume Down Volume Down
24 Back/Last Back Return or Status Return or Exit Enter Previous Channel
Prev CH or Instant
Replay
Return or Back Previous Channel Previous Channel Back
25 Options/Menu Options Menu or Setup
Options or Popup/
Title Menu
Start Menu Menu Setup Menu Menu Options
26 Up Move/Adust Up Up Up Up Up Up Up Up Up Up
27 Left Move/Adjust Left Left Left Left Left Left Left Left Left Left
28 OK OK Enter Enter Select Enter Select Enter Enter Enter Enter
29 Right Move/Adjust Right Right Right Right Right Right Right Right Right Right
30 Down
Move/Adjust
Down
Down Down Down Down Down Down Down Down Down
31 OSD OSD
HD Mode/SUB
On/Off
Home/Subtitle OSD Info OSD OSD
32 Sleep/Guide Sleep Disc Menu/Title Status/Display DVD menu Disc Menu Info Info Sleep
33 1 1 1 1 1 1 1 1 1 1 1
34 2 2 2 2 2 2 2 2 2
2 2
35 3 3 3 3 3 3 3 3 3 3 3

Harman Kardon AVR 1700 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	75 Ω
Audio output channels	- channels
Power output per channel (1KHz@8 Ohm)	100 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Number of HDMI outputs	1
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
3D	Yes
Analog signal format system	NTSC
Product color	Black
Audio decoders	Dolby Pro Logic, Dolby Pro Logic II, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	350 mm
Width	440 mm
Height	165 mm
Weight	5800 g
