AVR
4
Front-Panel Controls
Front-Panel Controls
Power Indicator/
Power Button
Message
Display
Volume
Knob
Surround Mode
Select Buttons
Set
Button
IR
Sensor
Channel
Level Control
Button
Source Select
Buttons
Left/Right
Buttons
Headphone Jack/
EzSet/EQ Mic
Connector
Tuning Mode Button/
RDS Button
Digital Input
Button
Surround-Mode
Category Button
Up/Down Buttons/
Tuning Buttons
USB/iPod
Port
Aux Analog
Audio Input
Connector

Table of Contents

Other manuals for Harman Kardon AVR 1700

Preview: Quick Setup Guide
Quick Setup Guide140 pages
Preview: Manual
Manual10 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Harman Kardon AVR 1700 and is the answer not in the manual?

Harman Kardon AVR 1700 Specifications

General IconGeneral
Receiver type-
Frequency range10 - 100000 Hz
Output impedance75 Ω
Audio output channels- channels
Power output per channel (1KHz@8 Ohm)100 W
Power output per channel (20-20KHz@8 Ohm)95 W
HDMI in6
Number of HDMI outputs1
Ethernet LANNo
FM band range87.5 - 108 MHz
Supported radio bandsFM
3DYes
Analog signal format systemNTSC
Product colorBlack
Audio decodersDolby Pro Logic, Dolby Pro Logic II, Dolby TrueHD, DTS-HD Master Audio
Volume controlRotary
Weight and Dimensions IconWeight and Dimensions
Depth350 mm
Width440 mm
Height165 mm
Weight5800 g
