MAIN REMOTE CONTROL FUNCTIONS
MAIN REMOTE CONTROL FUNCTIONS 11
3
D
G
B
I
1
2
0
4
5
6
7
8
9
A
C
E
F
H
J
L
N
O
P
Q
M
K
0
Power Off Button
1
Power On Button
2
LCD Information Display
3
Input Selectors
4
AVR Selector
5
Test Button
6
DSP Surround Mode Selector
7
Logic 7 Mode Select Button
8
Direct Button
9
Clear Button
A
EzSet/EQ On/Off Button
B
Tuning Mode Button
m Channel Select Button
n Navigation Button
o Digital Select Button
F
Set Button
G
Transport Play Buttons
H
Volume Up/Down Selectors
I
Transport Fast-Play/Scan Buttons
J
Main Transport Controls
K
Track Skip Up/Down Buttons
L
Preset Up/Down Button
M
Tuning Up/Down Button
N
Disc Skip Button
O
Program Button
P
Light Button
Q
Multiroom Button
Macro Buttons
Sleep Button
Night Mode Button
OSD Button
Tone Control Button
Dim Button
Tuner/FM Select Button
Channel Up/Down Selector
Delay Select Button
Speaker Select Button
Memory Button
Numeric Keys
Stereo Mode Select Button
DTS Neo:6 Mode Select Button
DTS Digital Mode Select Button
Dolby Mode Select Button
6-Channel/8-Channel Input Select
Mute Button
Lens
NOTES:
• The function names shown here are each button’s feature when used with the AVR 645.
Most buttons have additional functions when used with other devices. When a button is pressed,
the function name will appear in the bottom line of the
LCD Information Display c.
• The jack on the upper right side of the remote is reserved for future use. Do not remove the
plug provided or connect any device to the jack.
• To make it easier to follow the instructions that refer to this illustration, a larger copy may be
downloaded from the Product Support section for this product at www.harmankardon.com.
