Typographical Conventions
In order to help you use this manual with the remote control, front-panel controls and rear-panel connections,
certain conventions have been used.
EXAMPLE – (bold type) indicates a specific remote control or front-panel button, or rear-panel
connection jack
EXAMPLE – (OCR type) indicates a message that is visible on screen, or on the front-panel
information display
1 – (number in a square) indicates a specific front-panel control
A – (letter in a square) indicates a front-panel control that is normally concealed behind the drop-down door
¡ – (number in a circle) indicates a rear-panel connection
a – (number in an oval) indicates a button or indicator on the main remote control
å
– (letter in an oval) indicates a button on the ZR 10 remote control
Important note about the instructions in this manual: The appearance of the menus, text and/or cursor in your
receiver’s on-screen menus may vary slightly from the illustrations in this manual. Whether the text appears in
all uppercase or upper- and lowercase characters, performance and operation remain the same.
Please register your product on our Web site at www.harmankardon.com. Note: You’ll need the serial
number of your new AVR. At the same time, you can choose to be notified about our new products
and/or special promotions.
AVR 645 AUDIO/VIDEO RECEIVER
3 Introduction
4 Important Safety Information
4 Unpacking
5 Front-Panel Controls
8 Rear-Panel Controls
11 Main Remote Control Functions
15 ZR 10 Remote Control Functions
17 Installation and Connections
21 System Configuration
21 Speaker Placement
23 Input Setup
25 Audio Setup
25 Surround Setup
27 Using EzSet/EQ
30 Manual Setup
30 Speaker Size and Crossover
32 Delay Settings
33 Output Level Adjustment
36 Operation
36 Basic Operation
36 Source Selection
37 Volume and Tone Control
37 Surround Mode Selection
37 Digital Audio Playback
39 USB Playback
40 Using The Bridge
41 AM/FM Tuner Operation
41 XM Radio Operation
42 Recording
42 Front-Panel Connections
42 Output Level Trim Adjustment
43 Dim Function
44 Advanced Features
44 Front-Panel Display Fade
44 Display Brightness
44 Turn-On Volume
44 Semi-OSD Settings
45 Full-OSD Time-Out Adjustment
45 DMP/The Bridge Auto Power
46 Multiroom Operation
46 Multiroom Setup
46 Surround Channel Amplifier Assignment
47 Multiroom Operation
48 Configuring the Remote
48 Preprogrammed Code Entry
49 Automatic Code Entry
49 Learning Commands
50 Learning Codes for an Input Selector
51 Changing Devices
51 Macro Programming
53 Punch-Through Configuration
55 Renaming
56 Resetting the Remote
57 Device Priority Timing
59 Troubleshooting Guide
59 Processor Reset
60 Appendix
64 Technical Specifications
64 Trademark Acknowledgements
2 TABLE OF CONTENTS
For Canadian model
Modèle pour les Canadien
Cet appareil numérique de la classe B est conforme
à la norme NMB-003 du Canada.
Sur les modèles dont la fiche est polarisee:
ATTENTION: Pour éviter les chocs électriques, introduire
la lame la plus large de la fiche dans la borne
correspondante de la prise et pousser jusqu’au fond.
This class B digital apparatus complies with Canadian
ICES-003.
For models having a power cord with a polarized plug:
CAUTION: To prevent electric shock, match wide blade
of plug to wide slot, fully insert.
