Harman Kardon AVR 745 - Page 114

Ref. Designator Part Number
Description
MAIN PCB ASS'Y
N819 N820 N821 N823 H03-WN04AB100WH-R CONN WAFER 2.0MM 4P 35237-0410 WHT
P801 P802 P803 P804 H03-WN04SB100WH-R CONN WAFER 2.0MM 4P 35336-0410 WHT
P808 H03-WN05SD100WH-R CONN WAFER 2.5MM 5P 5267-05A WHT
P815 H03-WN07SB100WH-R CONN WAFER 2.0MM 7P 35336-0710 WHT
N822 H03-WN09AB100WH-R CONNECT WAFER 2.0mm 9P 35237-0910 WHT
P811 H03-WN09SB100WH-R CONNECT WAFER 2.0mm 9P 35336-0910 WHT
P816 H03-WN10SB100WH-R CONNECT WAFER 2.0mm 10P 35336-1010 WHT
P812 H03-WN13SB00000-R CONN 2.0MM 13P GIL-S-13P-S2T2
P813 H03-WN19SB00000-R CONN 2.0MM 19 MA ST NAT MOLEX 35336-1910 0 0
H03-ZMD27HS0400-R H/SINK REG. TR AVR745
NJ84 SO0A18P8CNN-R JACK-TELE SNAP-IN GOLDEN TELECOM GDL1-8P8C 8T BK 0 0
ZNSSM3023HZ-R NUT M3 ZN PLATED
ZSMBM3014BZ-R SCREW M.S M3X14 ZN PLATED
ZSTBM3010BB-R SCREW ST BH 3X10
H03-ZH740MSQ6WH-R MICA SHEET SIZE 19X22X0.05
PROCESSOR PCB
Capacitors
C125 C126 C127 C128 C141
C143 C144 C146 C190 C191
C206 C207 C212 C213 C220
C221 C226 C227 C230 C231
C232 C233 C251 C252 C253
C254 C301 C302 C303 C304
C307 C308 C309 C310 C508
C510 C517 C518 C521 C522
C528 C529 C534 C535 C601
C602 C611 C612 C617 C618
C621 C622 C627 C628 C631
C632 C637 C638 C641 C642
C647 C648 C752 C756
H03-CEHFC0106NN-R CE 10U0F +20% 16.0V 85C 5X11 P5MM SK 10/16V 5 X11
C175 C176 C193 H03-CEHIC01055E-R CE 1UF +20% 50V D5XL11 P5MM 85C SK 1/50V 5 X11
C607 C608 CEHGC0337NN-R CE 330UI0F +20% 25V 85C
C214 C215 C609 C610 H03-CEHFC01075E-R CE 100UF +-20% 16.0V D5XL11 P5MM 85C SK 100/16V 5 X11
C101 C102 C103 C104 C116
C117 C118 C119 C121 C122
C123 C124 C131 C132 C133
C134 C136 C137 C138 C139
C147 C148 C149 C150 C152
C153 C154 C155 C156 C157
C158 C159 C194 C195 C196
C197 C201 C202 C204 C205
C210 C211 C531 C603 C604
C757 C758
CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C281 C282 CZJII0121BE-R CAP CHIP 120PF 50V J NPO 0603
C208 C209 C222 C223 C624
C644
CZJII0151BE-R CAP CHIP 150PF 50V J NPO 0603
C532 C533 CZJII0330BE-R CAP CHIP 33P0F +5% -5% 50.0V NP0 0603
C751 CZKII0222BC-R CAP CHIP 2N2F +10% -10% 50.0V X7R 0603
C12 C13 C14 C15 C16 C17
C18 C19 C120 C135 C203
CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C224 C225 C238 C315 C316
C503 C506 C519 C520 C530
C540
CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C591 C592 C613 C614 C623
C633 C643
CZJII0151BE-R CAP CHIP 150PF 50V J NPO 0603
C605 C606 CZJII0271BE-R CAP CHIP, 270PF 50V +/-5% CH J 0603
C615 C616 CZJII0330BE-R CAP CHIP 33P0F +5% -5% 50.0V NP0 0603
C634 C636 C753 CZKII0222BC-R CAP CHIP 2N2F +10% -10% 50.0V X7R 0603
C10 C11 C20 C21 CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C625 C626 C635 C645 C646 CZJII0560BE-R CAP CHIP 56PF 50V CH J NPO 0603
AVR745
harman/kardon
114
