Ref. Designator Part Number
Description
RS232 PCB
BD31 H03-FB3012012CF-R FCM2012CF-301T04 0805
NJ60 H03-SO1R018H91E-R DA1R018H91E
STANDBY POWER SUPPLY
Capacitors
C113 C115 C118 C121 CCZID0104NA-R CC 100N0F +80% -20% 50.0V F
C102 C103 C104 C108 C109
C110
CCKIC0103NA-R CC 10N0F +10% -10% 50.0V Y5P
C101 CCMOC0472NF-R CC 4N7F +20% -20% 250.0V Y5V
C125 CEHGC0687NN-R CE 680U0F +20% 25.0V 85C
C114 CEHIC01055E-R CE 1UF +20% 50V D5XL11 P5MM 85C
C119 C120 CEHIC01065E-R CE 10U0F +20% 50.0V 85C P5MM 5X11
C107 C111 CEMGC04775E-R CE 470U0F +/-20% 25.0V 10X13 85C
C105 CEMJC02275E-R CAP ELEC 220UF 63V M 10X16 85C 120HZ ELITE
C106 H03-CEHIC0107NN-R CE 100U0F +20% 50.0V 85C P5.0MM
C116 H03-CEMJH0227NA-R CAP ELECTROYTIC,220uF 35V M 8x11 P=5MM
C203 C204 C205 H03-CFHOA0104NN-R CAP POLY METAL CPM 100NF 250V 20% TAE YANG
C100 CFMVA0104NN-R CPPMX 100N0F +20% -20%
C201 C202 H03-CEMJA0109KB-R CAP ELEC 10000UF 63V M 30X45 LSW103M1JP45M
Semiconductors
D101 D111 H03-DG1N04148NB-R D-SLP 1N4148 100.0V 150E-3A
D102 D103 D105 D106 D107
D108 D109 D112 D113 D117
D118 D121
H03-DR1N04004NA-R D-SR 1N4004 400.0V 1.0A
D119 D120 H03-DZGE22V05MA-R MZ0.5GE22V-5 22V 5mA
D116 H03-DZGE4V320MA-R MZ0.5GE4V3-20 4.3V 20mA
D104 H03-DZGE9V120MA-R MZ0.5GE9V1-20 9.1V 20mA
D201 H03-DURS10040NA-R RS1004 RS-10
IC12 H03-ICKIA7805I2-R IC-REGPOSFXD KIA7805API NORMAL TO-220IS +5V
IC11 H03-ICKIA78D3A0-R KIA78D33PI 3.3V
Resistors
R103 RC3DI0102IN-R RCF 1K0 OHM +5% 250MI0W
R102 R109 RC3DI0103IN-R RCF 10K0 OHM +5% 250MI0W
R110 RC3DI0104IN-R RCF 100K0 OHM +5% 250MI0W
R106 R107 RC3DI010AIN-R RCF 1R0 OHM +5% 250MI0W
R104 RC3DI0153IN-R RCF 15K0 OHM +5% 250MI0W
R105 RC3DI0222IN-R RCF 2K2 OHM +5% 250MI0W
R112 RC3DI0272IN-R RCF 2K7 OHM +5% 250MI0W
R113 RC3DI0470NN-R REC,CARBON,47,1/4W,+/-5%,SIZE=1/8W
R111 RC3DI0562IN-R RCF 5K6 OHM +5% 250MI0W
R115 R116 H03-RM3FC0100BN-R RES METAL OXIDE 10R OHM+5% 1.0W
R108 H03-RM3GC0330CN-R RESISTOR METAL OXIDE 33 OHM +5% 2.0W
Miscellaneous
FH10 FH12 FH23 FH24 H03-SOPS1FEHDNN-R TERMFUSEHLDR FUSE-HOLDER J4210020001X
Q101 Q102 H03-TRMPSA06NNA-R TR-SLPLF MPSA06 N 500MI0A TO-92
G101 G103 H03-ZNMSA4004SN-R TERMLUG GND
F101 H03-FUGF212A065-R FUSE 65TS SERIES 250V 12A 326012 USA ONLY
F201 H03-FUGF23000XX-R FUSE 239 SERIES 003 250V 3A 2183.15MXP USA ONLY
F101 H03-FUGF26A30XX-R FUSVDETIMELG 6.3A 250.0 V 5X20 21806.3MXP EUROPE ONLY
F201 H03-FUGF202A0XX-R FUSVDETIMELG 2.0A 250.0 V 5X20 218002MXP EUROPE ONLY
SK11 H03-RLL1227111K-R RELAY PWR 12.0V 270.0OHM 10.0A
NS31 H03-SOXA2202DNN-R A202D0031P 2P
NS30 H03-SOXA27014NN-R CON MAINS INLET A/C INLET 7014-NGP
TP11 H03-TXPWMR740B0-R AVR745 POWER TRANSFORMER (ST/BY)-120V USA ONLY
TP11 H03-TXPWMEI45B0-R AVR745EU POWER TRANSFORMER (ST/BY)-230V EUROPE ONLY
N307 H03-WG04SB82000-R WIRECONASY DL 2.0MM 04P 200MM UL1007 RIBBON 26 1
P305 H03-WN02SE00000-R CON 3.96MM PITCH HEADER 2 POS MOLEX 35328-0210
P306 H03-WN02SE00002-R CONNECT WAFER,YW396-03V 7.92mm 2P ,DONG HO
