Harman Kardon AVR 745 Service Manual

57. KIA278R33API (MAIN: IC71)
KIA278R06API (MAIN: IC73)
KIA378R05PI (SURROUND: IC64)
58. KIA7805API (MAIN: IC72 SUPPLY: IC12)
KIA7812API (MAIN: IC59 )
KIA7815API (MAIN: IC51, 60)
KIA7824API (MAIN: IC54)
KIA7806AP (VIDEO: IC30)
KIA78D33PI (SUPPLY: IC11 SURROUND: IC61)
59. KIA7915API (MAIN: IC52)
KIA7905PI (SURROUNDY: IC63)
1 2
3
4
1
2
3
1. INPUT
2. COMMON
3. OUTPUT
1
2
3
1. COMMON
2. INPUT
3. OUTPUT
AVR745
harman/kardon
81
