Ref. No.
Part No.
Description
R553,554,555
0RH0101G622
1 OHM 1 / 4
W 3216 5% D R/TP
R559,560,568,593,618
0RH0000C622
0 1/16
W 5 D.R/TP
R561,988
0RH1502C622
15K 1/16
W 5 D.R/TP
R562,861,863,981,983
0RH6802C622
68K 1/16
W 5 D.R/TP
R563
0RH2703C622
270K 1/16
W 5 D.R/TP
R586,589
0RH3301C622
3.3K 1/16
W 5 D.R/TP
R591,592,598,612,661
0RH1000C622
100 1/16
W 5 D.R/TP
R594
0RH7501C422
7.5K OHM 1 / 16
W 1608 1% D R/
R613,655,657,722,996
0RH4702C622
47K 1/16
W 5 D.R/TP
R614,867
0RH6801C422
6.80K 1/16
W 1% D R/TP
R616
0RH4700C622
470 1/16
W 5 D.R/TP
R617,974
0RH6801C622
6.8K 1/16
W 5 D.R/TP
R623
0RH4701C422
4.7K OHM 1 / 16
W 1608 1% D R/
R624,658,662,693,990
0RH1002C622
10K 1/16
W 5 D.R/TP
R632,654,709,717,718
0RH1002C622
10K 1/16
W 5 D.R/TP
R635,646,647,650,674
0RH0000C622
0 1/16
W 5 D.R/TP
R639,758
0RH2701C622
2.7K 1/16
W 5 D.R/TP
R640
0RH2701C622
2.7K 1/16
W 5 D.R/TP
R641,643,644,645
0RH4702C622
47K 1/16
W 5 D.R/TP
R642,690
0RH5600C622
560 1/16
W 5 D.R/TP
R649,651,668,679,684
0RH1000C622
100 1/16
W 5 D.R/TP
R670,686,687,998
0RH0000C622
0 1/16
W 5 D.R/TP
R677,694,864,971,972
0RH0000C622
0 1/16
W 5 D.R/TP
R692,696,697
0RH1001C422
1K 1/16
W 1% D R/TP
R701,702,703,704
0RH6801C622
6.8K 1/16
W 5 D.R/TP
R705,706,707,708
0RH1802C622
18K 1/16
W 5 D.R/TP
R710,906,925,975
0RH2201C622
2.2K 1/16
W 5 D.R/TP
R713,714
0RH1802C622
18K 1/16
W 5 D.R/TP
R715,716
0RH6802C622
68K 1/16
W 5 D.R/TP
R719,725,901,902,918
0RH1002C622
10K 1/16
W 5 D.R/TP
R723
0RH1502C622
15K 1/16
W 5 D.R/TP
R726,727,851,917,922
0RH4701C622
4.7K 1/16
W 5 D.R/TP
R730,751,752,753
0RH1000C622
100 1/16
W 5 D.R/TP
R732
0RH8200C422
820 OHM 1/16
W 1608 1% D R/TP
R754,961
0RH1003C622
100K 1/16
W 5 D.R/TP
R755
0RH5602C622
56K 1/16
W 5 D.R/TP
R756
0RH3302C622
33K 1/16
W 5 D.R/TP
R760
0RH7502C622
75K 1/16
W 5 D.R/TP
R761
0RH2703C622
270K 1/16
W 5 D.R/TP
R854,855,856,857
0RH2701C422
2.70K 1/16
W 1% D R/TP
R862,916,923
0RH1004C622
1M 1/16
W 5 D.R/TP
R907,908,927,928
0RH1203C622
120K 1/16
W 5 D.R/TP
R910,930
0RH8201C622
8.2K 1/16
W 5 D.R/TP
R911,915,924,929,931
0RH2202C622
22K 1/16
W 5 D.R/TP
R912,932
0RH1001C622
1K 1/16
W 5 D.R/TP
R919,976,978
0RH1002C622
10K 1/16
W 5 D.R/TP
R920,921,960
0RH1003C622
100K 1/16
W 5 D.R/TP
R933
0RH3303C622
330K 1/16
W 5 D.R/TP
R934,935
0RH3902C622
39K 1/16
W J D.R/TP
R936
0RH4703C622
470K 1/16
W 5 D.R/TP
R966,967,968,969
0RH0102C622
10 1/16
W 5 D.R/TP
CDR2
harm
an/kar
don
93
92
94
