Harman Kardon CDR2

To Next Page

To Previous Page

Ref. No.

Part No.

Description

R977

0RH4701C622

4.7K 1/16W 5 D.R/TP

R984,986

0RH6802C622

68K 1/16W 5 D.R/TP

R987,989,991,993

0RH0000C622

0 1/16W 5 D.R/TP

R994

0RH1002C622

10K 1/16W 5 D.R/TP

R997

0RH4702C622

47K 1/16W 5 D.R/TP

RESONATOR

X201

6212HA0202A

CSACV20.00MXJ040-TC20 MURATA 2

X202

6212HA3452B

CSACV34.57MXJ040-TC20 MURATA 3

X501

6212HA3382A

CSACV33.86MX040-TC20 MURATA 33

SWITCH

SW303

6600HXF101A

SPVF21001A ALPS . 5V 1MAV 4.65

TRANSISTOR

Q302,502,602,606

0TR144009AH

DTC144EK CHIP ROHM-J

Q503,607,608

0TR144009AH

DTC144EK CHIP ROHM-J

Q605

0TR144009AI

DTA144EK CHIP ROHM-J
