29
Do Not Burn Wet Coal!
Super-Magnum Coal Stoker Stove
3-90-02702R8_11/13
3. Distribution Blower
Requiresnolubrication.
Changeltermonthlytopreventbuildupofpethair,etc.
Toremovedistributionblower;
• Removelterretainerandlter.
• Disconnectthethreewiresfromtheblowerpowercord.
• Loosen3mountingscrewswhichholdthemotorintoits
housing.
• Lowerthemotorandsquirrelcagefanoutoftheblower
housing.
4. ESP- (Exhaust Sensing Probe)
Removeandwipecleanwithasoftclothandglasscleaner
or alcohol.
Toremovetheprobe,you'llneedtoaccessthepanelinthe
fuel hopper.
• Remove the knob from the heat exchange scraper
handle.Theknobisthreadedontotheshaft.
• Removetheaccesspanelbylooseningthescrews.
• With a 1/4" socket or driver, remove the screw that
attachestheprobe.
• Pulltheprobeoutofit'smountinghole.
Scraper Knob
Access Cover
ESP (probe)
5. Fines Scraper- in feeder
In the base of the hopper, there is a scraper plate that
keeps the coal nes owing toward the re. This scraper
plate is designed to be adjustable. To adjust, loosen the
two bolts with a 7/16" wrench, allow the scraper plate to
restdownwardagainstthetopofthepusherblock,andre-
tightenthetwobolts.
Mounting
Screws(3)

THE HOPPER.
LOOSEN THESE TWO BOLTS TO ADJUST THE
SCRAPER.
