Harmar Mobility AL030 - Default Chapter; Table of Contents

2
Contents
NOTE: The following symbols indicate areas where you should take
special care to avoid danger to individuals or property.
Section 1: Owner
OPERATING YOUR LIFT
General Operation .................................3
AL010/050 and AL030 Micro Lifts .....6
AL570 & AL570XL Lifts ..........................7
Using a Swing-Away ..............................8
Manual Override .................................. 10
SAFETY & MAINTENANCE 11
Section 2: Installer
PREPARATION
Tools Required ............................................13
Unpacking the Lift .....................................14
Installation Overview ...............................15
INSTALLATION
Wiring the Vehicle .....................................17
Vehicle Hitch ................................................19
Hitch Adapters ........................................... 20
Lift Installation
Hitch Post Mount ................................ 22
AL030 Bumper Mount ...................... 23
Swing-Away .......................................... 24
AL030 Power Tote Ball Mount ......... 26
CHAIR PREPARATION 27
Anchor Plate ......................................... 27
U-Bolt Kit ................................................ 28
LIFT ADJUSTMENTS
AL015 / AL100 / AL100HD / AL160 .. 29
AL010/050 and AL030 .........................31
AL560 & AL560XL ................................ 32
AL560 & AL580 Hold-Down Arm ... 33
AL570 & AL570XL Chair Plow .......... 34
Dock ‘N’ Lock: AL570 & AL570 XL ...35
TROUBLESHOOTING 37
EXPLODED VIEWS
AL030 ...................................................... 39
AL010/050 .............................................. 40
AL015 ........................................................41
AL100 ....................................................... 42
AL160 ....................................................... 43
AL300 ...................................................... 44
AL300RV ................................................. 45
AL301XL ..................................................46
AL500 ...................................................... 47
AL560 ...................................................... 48
AL560XL ................................................. 49
AL570 ...................................................... 50
AL570XL .................................................. 51
AL580 ...................................................... 52
AL580XL ................................................. 53
AL585SEL ................................................ 54
AL585SS .................................................. 55
AL100HD ................................................ 56
AL300HD ................................................ 57
AL301XLHD ............................................ 58
AL500HD ................................................ 59
ELECTRICAL HARDWARE 60
WARRANTY 63
WARNING
Hazardous situation. If not avoided,
could result in serious injury to
installer or user.
CAUTION!
Hazardous situation. If not
avoided, could result in serious
damage to property.
