Harmar Mobility AL030 - Al100

EXPLODED VIEW - AL100
ASSEMBLY PARTS
ITEM QTY
PART NO. DESCRIPTION
1 1 201-ZA06-C INNER TUBE
2 1 202-ZA06-C OUTER TUBE
3 1 203-ZA06-C PLATFORM
4 1 204-ZA06-C EXTENDED CRADLE BAR
5 1 205-ZA06-C HOLD DOWN ARM
6 2 501-ZA06-C SPREADER BAR BRACKET
7 2 502-ZA06-C BAR, LINK, 3/16"
8 1 ALA10010REV2 ACUTATOR
9 1 ALA10032 ROLLER 2" DIA UHMW
10 1 ALA10050 TAB, ACTUATOR
11 1 ALA10095 STICKER, OUTSIDE LIFT
12 1 ALA108-PLT HOLD DOWN ARM ROD
13 2 ALA11025 EXTENSION SPRING
14 1 ALA125SPI INSERTS, 1 1/4 BLACK PLASTIC
15 1 ALA13025 COMPRESSION SPRING
16 2 ALA13030 NYLINEAR BEARINGS - 3/4"
17 2 ALA13050P HOLD DOWN ARM WASHER
18 1 ALA14096 RED REFLECTOR
19 1 ALA180 HARDWARE PACK
20 1 ALA18020 HOLD DOWN FOOT
21 1 ALA99995 LABEL, SERIAL NUMBER
22 6 BHCS-0_37-16--0_75-SS BUTTON HEAD, 3/8-16 x 0.75, SS
23 1 BHCS-0_37-16--1_00-SS-NP BUTTON HEAD 3/8-16 x 1.00 SS
24 2 BHCS-10-24--0_50-SS BUTTON HEAD, #10-24 X 0.50, SS
25 1 H10096 STICKER, PLATFORM
26 1 H11010 J-CAM
PART NO.
QTYITEM
DESCRIPTION
ASSEMBLY PARTS
CLEVIS PINH14045129
WASH-0_62-1_08--0_15-SL-Z
WASH-0_50-1_50--0_12-N
WASH-0_50-1_06--0_08-RH-SS
WASH-0_25-0_62--0_04-RH-SS
SPCR-0_25-0_50--0_31-N
PIN-0_50--3_00-CL-Z
PIN-0_12--1_50-CO-SS
NUT-0_50-13-NYLOCK-Z
NUT-0_50-13-NYLOCK-NTE-Z
NUT-0_37-16-NYLOCK-NTE-Z
NUT-0_25-20-NYLOCK-Z
HHCS-0_50-13--2_50-Z
HHCS-0_50-13--0_75-Z
HHCS-0_25-20--1_75-Z
HHCS-0_25-20--0_75-NP-Z
PIN-0_18--1_50-RP-Z143
2
4
5
10
1
1
2
9
1
52
51
50
49
48
47
45
46
44
SHSB-0_62--2_50-Z
RR-0_62-EC-Z
RIV-188-SS
1
2
2
3
2
6
3
4
2
2
3
1
1
36
42
41
40
39
38
37
34
35
33
32
31
30
NUT-10-24-NYLOCK-Z
NUT-0_62-11-JAM-Z
HWTS-14--0_75-Z
H14407
ROLL PIN, 3/16, SPLIT, ZP
WASHER, SPLIT-LOCK, 5/8 , ZP
WASHER, FLAT, 1/2", NYLON
WASHER, FLAT, 1/2", SS
WASHER, FLAT, 1/4", SS
SPACER, 1/4", for CAM SPRINGS
SHOULDER BOLT, 5/8 DIA x 2.50, ZP
E-CLIP, 5/8" SHAFT
CLEVIS PIN, 1/2" x 3" L, ZP
RIVET
COTTER PIN
NUT, NYLOCK, #10-24, ZP
NUT, JAM, 5/8-11, ZP
NUT, NYLOCK, 1/2-13, ZP
THIN NUT, NYLOCK, 1/2-13, ZP
THIN NUT, NYLOCK, 3/8-16, ZP
NUT, NYLOCK, 1/4-20, ZP
HEX WASHER, #14 SELF DRILL, 0.75, ZP
HEX HEAD, 1/2-13 x 2.50, ZP
HEX HEAD, 1/2-13 x 0.75, ZP
HEX HEAD, 1/4-20 x 1.75, ZP
HEX HEAD, 1/4-20 x 0.75, ZP
ALUMINUM PLATE
1
127
28 H14044
200-2A01-A MOTOR COVER ASSEMBLY
ROLLER
38
2
32
2
34
2
22
6
33
2
36
1
46
2
8
1
10
1
5
1
12
1
13
2
4
1
6
2
15
1
16
2
7
2
17
2
20
1
31
1
42
1
1
1
2
1
26
1
3
1
27
1
28
1
29
1
40
2
44
1
43
1
47
1
48
1
52
2
50
1
49
10
36
2
32
1
50
2
50
2
9
1
23
1
30
1
39
3
51
4
45
9
11
1
35
4
21
1
25
1
19
1
18
1
41
2
24
2
37
6
14
1
29
Outside Lifts - Installation & Owner’s Manual 2013
43
Section 2 : inStaller
Exploded Views
AL100
