Harmar Mobility AL030 - Al500

48
Section 2 : inStaller
Exploded Views
AL500
ASSEMBLY PARTS
ITEM QTY
PART NO. DESCRIPTION
1 1 201-ZA06-C INNER TUBE
2 1 202-ZA10-C OUTER TUBE
3 1 203-ZA10-C PLATFORM
4 1 ALA10010REV2 ACUTATOR
5 1 ALA10032 ROLLER 2" DIA UHMW
6 1 ALA10050 TAB, ACTUATOR
7 1 ALA10095 STICKER, OUTSIDE LIFT
8 2 ALA11025 EXTENSION SPRING
9 1 ALA14096 RED REFLECTOR
10 1 ALA180 HARDWARE PACK
11 1 ALA50099 PATENT STICKER
12 1 ALA580 U-BOLT HARDWARE KIT
13 1 ALA58040C ANCHOR PLATE
14 1 ALA99995 LABEL, SERIAL NUMBER
15 1 BHCS-0_37-16--1_00-SS-NP BUTTON HEAD 3/8-16 x 1.00 SS
16 2 BHCS-10-24--0_50-SS BUTTON HEAD, #10-24 X 0.50, SS
17 1 H10096 STICKER, PLATFORM
18 1 H11010 J-CAM
19 1 200-2A01-A MOTOR COVER ASSEMBLY
20 1 H14044 ROLLER
21 1 H14045 CLEVIS PIN
ASSEMBLY PARTS
DESCRIPTIONPART NO.
QTYITEM
WASH-0_50-1_50--0_12-N
WASH-0_50-1_06--0_08-RH-SS
WASH-0_25-0_62--0_04-RH-SS
SPCR-0_25-0_50--0_31-N
PIN-0_50--3_00-CL-Z
PIN-0_12--1_50-CO-SS
NUT-0_50-13-NYLOCK-Z
NUT-0_50-13-NYLOCK-NTE-Z
NUT-0_25-20-NYLOCK-Z
HHCS-0_50-13--2_50-Z
HHCS-0_50-13--0_75-Z
HHCS-0_25-20--1_75-Z
HHCS-0_25-20--0_75-NP-Z
232
4
5
2
2
9
2
41
40
39
38
37
36
1
34
35
33
1
1
RR-0_62-EC-Z
NUT-10-24-NYLOCK-Z
RIV-188-SS
4
4
2
4
2
2
125
31
30
29
1
27
28
26 1
23
24
22 1
HWTS-14--0_75-Z
H50011B
H50010B
H14407
NUT, NYLOCK, 1/2-13, ZP
WASHER, FLAT, 1/2", NYLON
WASHER, FLAT, 1/2", SS
WASHER, FLAT, 1/4", SS
SPACER, 1/4", for CAM SPRINGS
E-CLIP, 5/8" SHAFT
CLEVIS PIN, 1/2" x 3" L, ZP
COTTER PIN
NUT, NYLOCK, #10-24, ZP
RIVET
THIN NUT, NYLOCK, 1/2-13, ZP
NUT, NYLOCK, 1/4-20, ZP
HEX WASHER, #14 SELF DRILL, 0.75, ZP
HEX HEAD, 1/2-13 x 2.50, ZP
HEX HEAD, 1/2-13 x 0.75, ZP
HEX HEAD, 1/4-20 x 1.75, ZP
HEX HEAD, 1/4-20 x 0.75, ZP
RIGHT HAND, Q-STRIANT - BLUE
LEFT HAND, Q-STRAINT - BLUE
ALUMINUM PLATE
26
1
28
2
30
1
37
2
4
1
6
1
8
2
25
1
34
1
1
1
2
1
18
1
3
1
19
1
20
1
21
1
35
1
38
1
40
1
39
2
40
2
40
2
5
1
15
1
22
1
41
4
36
9
7
1
29
4
14
1
17
1
10
1
9
1
33
2
24
2
23
2
27
4
31
4
12
1
16
2
11
1
13
1
32
2
EXPLODED VIEW - AL500
34
