ASSEMBLY PARTS
ITEM QTY
PART NO. DESCRIPTION
1 1 201-ZA08-C INNER TUBE
2 1 202-ZA08-C OUTER TUBE
3 1 203-ZA08-C PLATFORM
4 1 204-ZA06-C EXTENDED CRADLE BAR
5 2 501-ZA06-C SPREADER BAR BRACKET
6 1 ALA10010REV2 ACUTATOR
7 1 ALA10032 ROLLER 2" DIA UHMW
8 1 ALA10050 TAB, ACTUATOR
9 1 ALA10095 STICKER, OUTSIDE LIFT
10 1 ALA14096 RED REFLECTOR
11 1 ALA15152R1 T-HANDLE 1/2" SPRING PIN ASSY
12 1 ALA180 HARDWARE PACK
13 1 ALA50099 PATENT STICKER
14 1 ALA580 U-BOLT HARDWARE KIT
15 1 ALA58040C ANCHOR PLATE
16 1 ALA99995 LABEL, SERIAL NUMBER
17 6 BHCS-0_37-16--0_75-SS BUTTON HEAD, 3/8-16 x 0.75, SS
18 2 BHCS-10-24--0_50-SS BUTTON HEAD, #10-24 X 0.50, SS
19 1 H10096 STICKER, PLATFORM
ASSEMBLY PARTS
ITEM QTY
PART NO. DESCRIPTION
WASH-0_50-1_06--0_08-RH-SS
NUT-0_50-13-NYLOCK-NTE-Z
NUT-0_37-16-NYLOCK-NTE-Z
HHCS-0_25-20--0_75-NP-Z
37
36
2
5
133
35
34
9
1
32
31
2
2
WASH-0_50-1_50--0_12-N
RIV-188-SS
PIN-0_50--3_00-CL-Z
PIN-0_12--1_50-CO-SS
NUT-10-24-NYLOCK-Z
NUT-0_50-13-NYLOCK-Z
29
30
28
6
4
4
26
27
25
2
2
2
222
24
23
1
2
21
20
1
1
HHTS-12-14--0_75-Z
HHCS-0_50-13--2_50-Z
HHCS-0_50-13--0_87-Z
HHCS-0_50-13--0_75-Z
H50010B
H50011B
H14407
200-2A01-A
THIN NUT, NYLOCK, 1/2-13, ZP
WASHER, FLAT, 1/2", NYLON
WASHER, FLAT, 1/2", SS
RIVET
CLEVIS PIN, 1/2" x 3" L, ZP
COTTER PIN
NUT, NYLOCK, #10-24, ZP
NUT, NYLOCK, 1/2-13, ZP
THIN NUT, NYLOCK, 3/8-16, ZP
HEX WASHER, #12-14 SELF DRILL, 3/4" L, ZP
HEX HEAD, 1/2-13 x 2.50, ZP
HEX HEAD, 1/2-13 X 0.88, ZP
HEX HEAD, 1/2-13 x 0.75, ZP
HEX HEAD, 1/4-20 x 0.75, ZP
RIGHT HAND, Q-STRIANT - BLUE
LEFT HAND, Q-STRAINT - BLUE
ALUMINUM PLATE
MOTOR COVER ASSEMBLY
1
1
2
1
6
1
7
1
8
1
9
1
5
2
10
1
11
1
12
1
14
1
16
1
17
6
18
2
19
1
20
1
21
1
23
2
24
1
27
2
25
2
28
4
29
6
31
2
32
2
33
1
34
1
35
9
36
5
22
2
30
4
3
1
13
1
15
1
37
2
4
1
26
2
EXPLODED VIEW - AL300RV
46
Section 2 : inStaller
Exploded Views
AL300RV
