Harmar Mobility AL350 - Default Chapter; Table of Contents

2
Contents
NOTE: The following symbols indicate areas where you should take
special care to avoid danger to individuals or property.
Section 1: Owner
OPERATING YOUR LIFT
General Operation .................................3
Using a Swing-Away ..............................6
Manual Override .................................... 8
9
SAFETY & MAINTENANCE
Section 2: Installer
PREPAR ATION
Tools Required ............................................11
Unpacking the Lift .....................................12
Installation Overview ...............................13
INSTALLATION
Wiring the Vehicle .....................................15
Vehicle Hitch ................................................18
Hitch Adapters ........................................... 19
Lift Installation
Hitch Post Mount ................................ 21
Swing-Away ................................................ 23
CHAIR PREPARATION 25
Anchor Plate ......................................... 25
U-Bolt Kit ................................................ 26
27
30
TR
OUBLESHOOTING
WIRING DIAGRAM
EXPLODED VIEWS
WARRANTY
35
WARNING
Hazardous situation. If not avoided,
could result in serious injury to
installer or user.
CAUTION!
Hazardous situation. If not
avoided, could result in serious
damage to property.
| www.harmar.com | 800-833-0478
