3
SECTION 1 : OWNER
Operating Your Lift
GENERAL OPERATION
1. LOWERING THE LIFT
Insert key and switch to ‘ON’ position.Press
‘DOWN’ on toggle switch. The platform will
unfold. Continue to lower until platform reaches
the ground and becomes level. [Figure 3-1]
DO NOT over-lower to the point where the
vehicle begins to rise. This will damage the lift.
IMPORTANT
Positioning the chair properly on the platform is
critical to ensure it is properly locked onto the lift.
Always verify wheels are captured by cradles
or bars. Please consult your dealer on the specics
of your application.
Figure 3-1
Figure 3-2
2. DRIVE ONTO PLATFORM.
Drive slowly, stopping when the drive wheels fall
between the platform bars if applicable. [Figure
3-2]
AL350 Hitch-Mounted Scooter and Power Chair Lift P/N: 610-00065 Rev A
